Well Information
(Click to Collapse...)

Identification
Type of Report: Water Well
Type of Work: ALTERATION
Well Report: KLAM 62255 View Log Groundwater Site
Well Label: 158397
Start Card: 1078211
Original Report: KLAM 11829 View Original Log
Owner Well Nbr:
Company Job Nbr:
Primary Use: THERMAL
Complete Date: 08/11/2025
Land Owner
Name: OREGON INSTITUTE OF TECHNOLOGY
Company: OIT
Address: 3201 CAMPUS DR, KLAMATH FALLS

KLAMATH FALLS, OR 97601
Location
(Click to Collapse...)

Latitude/Longitude
Latitude: 42.25279000
Longitude: -121.78181300
Horiz. Error: 99.00 ft.
Location
County: KLAM
TRSQQ: WM38.00S9.00E20SENE
Tax Map:
Tax Lot: 4900
Lot:
Block:
Subdivision:
Street of Well: 3201 CAMPUS DR, KLAMATH FALLS, KLAMATH FALLS, OR 97601
WM District: 17
Surface Elev: 4429.85 FT
Well Report Mapping Tool
Tax Lots

Note: Tax lot overlay available only for a few counties.
Well Construction
(Click to Collapse...)

Construction
Start Date: 08/11/2025
Completed Date: 08/11/2025
Drill Method: Rotary Air
Depth of Completed Well: 1805.00
Est. Depth Drilled: 12.00
Special Standards:
Seal Placed Method: OTHER - POURED DRY&HYDRAT
Abandonment Start Date:
Abandonment Completed Date:
Backfill
Backfill Placement: ft to ft
Backfill Material:
Explosives Used:
Explosive Type:
Explosive Amount:
Filter Pack
Filter Pack:
Filter Pack Material:
Filter Pack Size:
Bore Hole
Seal
RowMaterialFrom (ft)To (ft)AmountAmount Calc.
1Bentonite Chips0.0012.0022.0019.26
Abandonment Log
No data matches search criteria.
Casing/Liner
RowCasing/LinerDiameter (in)Above Land SurfaceFrom DepthTo (ft)GaugeMaterialWeldGlueThreadShoe
Inside		Shoe
Outside		Shoe
Other		Shoe
Location
1Casing12.00 ● 2.00 12.00 0.250 - Gauge Steel ●
2(Casing)Pre-Alteration12.00 ● 2.00 416.25 0.250 - Gauge Steel ●
Temporary Casing
No data matches search criteria.
Perforations
No data matches search criteria.
Screens
No data matches search criteria.
Well Test
Temperature:
Lab Analysis:
Lab Analysis Done By:
Total Dissolved Solids:
Water Quality Concerns:
Well Test
No data matches search criteria.
Analysis
No data matches search criteria.
Static Water Level
(Click to Expand...)

Static Water Level
Depth First Water:
Pre-Static Water Level:
Pre-Static Water Level Date:
Post-Static Water Level:
Post-Static Water Level Date:
Static Water Level
No data matches search criteria.
Lithology
(Click to Expand...)

Material
RowFromToMaterialStatic Water Level
10.001805.00CASING HEIGHT ALTERATION
Well Constructor
(Click to Expand...)

Bonded Driller Name: KYLE HUGHES
Bonded Driller Company: NORM SEVEY WELL DRILLING
Bonded Driller Number: 1983
Bonded Date Signed: 09/05/2025
Unbonded Name:
Unbonded Company:
Unbonded Number:
Unbonded Date Signed:
Other Name:
Other Affiliation:
Other License Nbr:
Geologist Engineer:
Comments
(Click to Expand...)

Comments
We cut off the old decayed 12" casing at 12 ft below ground surface. We then replaced the 12" casing with new 12", .250 casing. It was attached with a casing collar. A 16" pipe was the fitted over the 12" casing where we were able to fill the space with 3/8 Bentonite after the native soil had been replaced. Plan was approved by OWRD per Tommy Laird.
Documents
(Click to Expand...)

TitleDocument TypeSourceDownload Image
Sketch of Proposed WorkDIAGRAMDRILLERImage
Sketch of Proposed WorkDIAGRAMDRILLERImage
Condition Of 12 Inch Casing 1PHOTODRILLERImage
Condition Of 12 Inch Casing 2PHOTODRILLERImage
Condition Of 12 Inch Casing 3PHOTODRILLERImage
Special Standards DenialSPECIAL STANDARD FINAL ORDEROWRDImage
KLAM 62255WELL REPORTDRILLERImage
